Spec description
Audio Input Balanced Input (Rear)1 pairConnectorsXLR-3-31 (1:GND, 2:HOT, 3:COLD)Impedance20k ohmsSensitivity2VrmsLine Input (Rear)2 pairs （LINE1, LINE2）ConnectorsRCA Pin Jack (Gold-plated)Impedance10k ohmsSensitivity1VrmsAuxiliary Input (Front, AUX) Connectors1/8" (3.5mm) Stereo Mini JackImpedance13k ohmsSensitivity0.5VrmsAudio Output Headphone Output (Front) Connectors1/4" (6.35mm) Stereo JackSupported Headphone Impedance16 ohms - 600 ohmsMax Output Level1,400mW + 1,400mW (at 32 ohms)
135mW + 135mW (at 600 ohms)Rated Output Level600mW + 600mW (at 32 ohms)
34mW + 34mW (at 600 ohms)THD0.002% (Input 1V, Output 1V, at 32 ohms)
0.01% (Input 1V, Output 600mW, at 32 ohms)S/N Ratio110dB (RCA Input, 2Vrms 1kHz, A-weighted)Frequency Response2Hz – 100kHz (+0dB/-3dB)
10Hz – 100kHz (+/-3dB)Line Output (Rear) ConnectorsRCA Pin Jack (Gold-plated)Impedance100 ohmsOutput Level316mVOutput Level SelectorFixed, Variable, OffOperation Power120V AC, 60Hz (US/Canada)
230V AC 50Hz (UK/Europe)Power Consumption22W (Standby: 0W)Operating Temerature+5˚C to +35˚C
+41˚F to +95˚FOperating Humidity5% to 85% (no condensation)Storage Temerature-20˚C to +55˚C
-4˚F to +131˚COverall Dimensions290 (W) x 81.2 (H) x 244 (D) mm, 11.4" (W) x 3.2" (H) x 9.6" (D)Net Weight4.1kg, 9 lbsAccessoriesAC Cable, AC Plug Adapter (3P-2P),
)
)
