Technical data

Principle: triple conversion superhet, IF 70.455 MHz, 455 kHz, 97 kHz.
Operation modes: A1, SSB, AM (A3), AM sync., FM-n (F3)
Frequency range: 100 kHz - 30 MHz
Frequency display: digital display, 10 Hz
Frequency memory: 200 memories
Signal strength indicator: S-meter
Signal processing: RF gain, AGC x 3, PBT, noise blanker, notch filter
Features: Scan - Functions, Clock / Timer, RS-232 - Interface
Sensitivity: 100 kHz - 500 kHz AM < 15.8 ?V, SSB < 5 ?V;
Sensitivity: 500 kHz - 1.6 MHz AM < 6.3 ?V, SSB < 2 ?V;
Sensitivity: 1.6 - 30 MHz AM < 2 ?V, SSB < 0.32 ?V, FM < 0.5 ?V
Selectivity: AM wide 6/15 kHz, inter 2/6 kHz, narrow* 1/3 kHz, aux/FM 12 kHz & variable bandwidth (-6/-60 dB).

Power supply
Mains operation: 110, 220 V AC
Battery operation: 12 - 16 V DC from an external power source
