Technical Specifications
Expansion / Connectivity
Interfaces
2 x 1000Base-T - RJ-45 (WAN)
16 x 1000Base-T - RJ-45
1 x management - RJ-45
2 x USB - Type A
1 x 1000Base-T - RJ-45 (DMZ)
1 x 1000Base-T (management) - RJ-45
2 x 1000Base-T - RJ-45
Miscellaneous
Compliant Standards UL, VCCI, C-Tick, ICSA IPSec certified, ICSA Firewall certified, cUL, ICSA Antivirus, CB, FCC Part 15 A, ICSA Network IPS
Networking
Capacity
Gateway to gateway IPSec VPN Tunnels: 1500
Client to gateway IPSec VPN tunnels: 5000
Concurrent sessions: 2500000
New sessions per second: 22000
Concurrent SSL VPN users: 200
Firewall policies: 10000
Virtual domains: 10
User licenses: unlimited
Connectivity Technology Wired
Data Link Protocol Ethernet, Fast Ethernet, Gigabit Ethernet
Encryption Algorithm SSL
Features Firewall protection, VPN support, antivirus analysis, High Availability, Intrusion Prevention System (IPS), anti-spam protection, anti-malware protection
Form Factor External
Network / Transport Protocol IPSec
Performance
Firewall throughput (1518-byte packet size): 2.5 Gbps
Firewall throughput (512-byte packet size): 1 Gbps
Antivirus throughput: 700 Mbps
IPS throughput: 950 Mbps
Antivirus throughput (proxy): 300 Mbps
Status Indicators Power, status, alarm, link/activity
Switching Protocol Ethernet
