EQUINOX Helix Scan XP 150W Scanner MovingLight

Helix Scan XP 150W Scanner (Demogerät Neu)

EQLED204 - Black Housing

Helix Scan XP 150W Scanner

Product overview

The Helix Scan XP is a powerful scanner which packs a punch over long distances thanks to its superior optics

and high output 150W LED. The motorised focus allows crisp gobos to be projected, whilst a 3 facet rotating prism

allows for projections to be split covering a larger area. All 8 gobos are interchangeable along with a separate

colour wheel featuring 9 colours plus open. To further enhance this effect, an additional 11-piece gobo pack

is also included to cover many popular events and celebrations. Clever programming allows users to select a

single gobo and then have specific colours from the colour wheel added to them manually, whilst being activated

automatically or via sound. The Helix Scan XP can be linked with the Helix Roller XP and Helix XP to create

• 1 x 150W cool white LED (8000K)

• Beam angle: 15°

• 9,645 Lux @ 2m

• CRI: 72

• Refresh rate: 5kHz

• Motorised focus

• 3 facet circular rotating prism

• 8 rotating, replaceable gobos

• 9 colours + open

• DMX channels: 2/10 or 12 selectable

• Auto, sound active and master/slave modes

plus built-in programs

• Pan: 130°, Tilt: 42°

• 0-100% dimming

• Variable strobe

• Optional CA 8 controller

• Bracket allows for multiple rigging

or floor standing applications

• 4 button menu with LED display

• PowerTwist input/output

• 3-Pin XLR input/output

• Fan cooled

• Supplied with an additional gobo pack

containing 11 popular gobos

• Linkable with the Helix Roller XP and Helix XP
