Oggetti in condizioni perfette.
Periodo d'oro Kenwood in pieno boom hifi.
Manufacturer: Kenwood
Model: Basic C 1
Type: Preamplifier
Years of manufacture: 1983 - 1990
Made in: Japan
Color: Black(black anodized)
Remote control: No
Power consumption: 17 W
Dimensions: 440 x 78 x 326 mm WxHxD
Weight: 4.2 kg
Original price approx.: 498 DM
Connections
Number of inputs:
Phono MC: 0,25mV,100Ohm
Phono MM: 2,5mV, 47kOhm
CD/Tuner/Aux/Tape: 150mV, 47kOhm
Number of outputs:
Tape Rec Out A/B
Pre Out: 1V
Specifications
Frequency Response:
CD/Tuner/Aux/Tape: 1Hz-350kHz.
Phono: 20Hz-20kHz
Distortion factor:
CD/Tuner/Aux/Tape: 0.004%
Phono: 0.005%
Signal-to-noise ratio:
Phono MC/MM: 70/87dB
CD/Tuner/Aux/Tape: 108dB
Stereo channel separation:
Tone control
Bass: ± 10 dB
Treble: ± 10 dB
Loudness: 0 to + 9 dB continuously adjustable
High Filter: + 10 dB at 10 kHz
Low Filter (Subsonic): 18Hz, 6dB/Oct
Mute:
Manufacturer: Kenwood
Model: Basic M 1
Type: Power amplifier
Years of manufacture: 1983 - 1987
Made in: Japan
Color: Black (anodized aluminum)
Remote control: No
Power consumption: 700 W max.
Dimensions: 440 x 112 x 324 mm (WxHxD)
Weight: 9.1 kg
Original price approx.: 698 DM
Connections
Number of inputs:
Main In: 1V/47kOhm
Number of outputs:
Speaker: A/B
Sigma Drive connections (only speaker pair A)
no Sigma Drive when using both speaker pairs
Speaker impedance 4 - 16 Ohm
Technical Data
Continuous power (at distortion factor)
8 Ohm: 2 x 105 Watt (20 Hz - 20 kHz @ 0,004%)
4 Ohm: 2 x 150 Watt (63 Hz - 12,5 kHz @ 0,7%)
Dynamic power
8 Ohm: 2 x 170 Watt (1 kHz)
4 Ohm: 2 x 210 Watt (1 kHz)
Total harmonic distortion: 0.003%
Attenuation factor: 1,000 (100 Hz) with Sigma Drive
Frequency response: 1 Hz - 300 kHz (-3dB)
Signal-to-noise ratio: 120 dB
Special Features
Super DLD (Dynamic Linear Drive).
HiFi power amplifier built in completely discrete analogue circuitry with impressive sound quality, stable load behaviour at impedances up to 1 Ohm!
