Active Crossover CX-2315 NADY

NADY CX-2315 3-Way Stereo/ 4-Way Mono Active Crossover

Originalvepakt und geprüft

• Single rack space (1U) metal housing
• Top audio performance with high slew rate circuitry and over 115dB dynamic range for clear transparent sound
• Designed for the most precise accurate control
• Phase inversion switches
• Low-cut subsonic filters for low frequency driver protection Servo-balanced XLR inputs
• Switchable constant directivity horn equalization circuit for use with horns requiring a high frequency boost
• State-variable Linkwitz Riley 24dB/ octave filters
• Shielded internal power supply with AC voltage select switch (~115V/60Hz or ~230V/50Hz)

SPECIFICATIONS:

• Frequency Response
• Low Frequency Output: 10HZ +/- 0.5dB
• High Frequency Output: 20KHz +/-1.0dB
• Total Harmonic Distortion
• RL: >2k?
• Low Frequency Output: < 0.01% THD
• High Frequency Output: <0.02% THD
• Maximum Output Level
• RL: >2k? +21 dBu (6.2 volts) @ < .05% THD 20Hz - 20kHz
• Maximum Voltage Gain: 6dB
• Constant-Directivity Correction: +3dB @ 3.5kHz rising at 6 dB/octave to 22.5kHz
• Frequency Range
• Low Mid (X1): 100Hz to 920Hz
• Mid-High (X10): 800Hz to 9.2kHz
• Hum and Noise (20Hz- 20kHz): Av=0 dB. fc=230.2.3kHz
• Low Frequency Section
• Output @0dB: <-98dBu
• Mid Frequency Section
• Output @ 0dB: <-95dBu
• High Frequency Section
• Output @ 0dB: <-93dBu
• Signal-To-Noise Ratio: 114dB
• Controls
• Input Level: Continuously variable
• Output Level: Low, High cont. Variable
• Phase: Rear panel switch
• Mute: Low. Mid, High front panel switches
• CDBoost: Rear panel switch
• Channel link: Rear panel switch
• Dimensions: 483 x 194.5 x 44 mm
• Weight: 2.5 Kg
