Equivalent to 40- to 46-size glow engine for planes weighing 4-7 lb (1.8-3.2 kg)
Ideal for 25- to 40-size 3D airplanes up to 5 lb (2.2 kg)
Ideal for models requiring up to 925 watts of power
Type: Brushless outrunner
Size: Replacement for 40- to 46-size glow engines
Bearings or Bushings: One 6 x 15 x 5mm Bearing, and Two 6 x 12 x 4mm Bearing
Wire Gauge: 14
Recommended Prop Range: 12x8 to 14x10
Voltage: 14.4 to 19.2
RPM/Volt (Kv): 670
Resistance (Ri): .04 ohms
Idle Current (Io): 3.90A @ 10V
Shaft Diameter: 6mm (.24 in)
Overall Length: 55mm (2.15 in)
Weight: 290 g (10.0 oz)
Overall Diameter: 50mm (2.00 in)
Diameter: 50mm (2 in)
Length: 55mm (2.15 in)
Continuous Current: 40A
Maximum Burst Current: 55A (15 sec)
Cells: 12-16 Ni-MH/Ni-Cd or 4-5S Li-Po
Speed Control: 60A brushless
)
)
)
