Video Inputs
1x 10-bit HD/SD-SDI switchable via DIN 1.0/2.3 connector
1x HDMI type A connector
Video Outputs
1x 10-bit HD/SD-SDI switchable via DIN 1.0/2.3 connector
1x HDMI 1.3 type A connector
Audio Inputs
SDI: 16 channels embedded in SD and HD in QuickTime files / 2 channels in Avid DNxHD MXF files.
HDMI: 8 channels embedded in SD and HD in QuickTime files / 2 channels in Avid DNxHD MXF files.
Audio Outputs
SDI: 16 channels embedded in SD and HD in QuickTime files / 2 channels in Avid DNxHD MXF files.
HDMI: 2 channels embedded in SD and HD
SSD Interface
1x 2.5" SATA 3 Gb/s
Recorder Control
7 buttons for local control of HyperDeck Shuttle 2, or use USB 2.0 high-speed interface
Recorder Configuration
Use USB 2.0 high speed interface
Computer Interface
1x Mini-B type USB 2.0 connector for initial setup, software updates, and HyperDeck Utility software control
Standards
SD Format Support
625/25 PAL and 525/29.97 NTSC
480p60 and 576p50 via HDMI only
HD Format Support
720p50, 720p59.94, 720p60, 1080i50, 1080i59.94, 1080i60, 1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30
SDI Compliance
SMPTE 259M, SMPTE 292M
SDI Metadata Support
HD RP188 and closed captioning
Video Sampling
4:2:2
Audio Sampling
Television standard sample rate of 48 kHz and 24-bit
Color Precision
10-bit
Color Space
REC 601, REC 709
Multiple Rate Support
SDI and HDMI switches between 270 Mb/s SD-SDI and 1.5 Gb/s HD-SDI
Copy Protection
HDMI input is unable to capture from copy protected HDMI sources. Always confirm copyright ownership before capture or distribution of content.
Codec Support
Uncompressed 10-bit QuickTime, Apple ProRes 422 (HQ) QuickTime, Avid DNxHD QuickTime, Avid DNxHD MXF.
Battery
Rechargeable built-in lithium-ion polymer battery
Power Supply
12V universal power supply included with international socket adapters for all countries. Connection supports 12-18 V
Dimensions
4.6 x 6.1 x 1" (11.7 x 15.5 x 2.5 cm)
)
