Environment
Power consumption 12W, 40.94 BTU/hr (idle)
20.4W, 69.6 BTU/hr (full load)
Operating temperature 0-40°C (operating)
-20 to +80°C (storage)
Humidity 10%-90%, non-condensing
Product Certifications
Certifications CB, UL, CE, FCC, ISED, VCCI, MIC (Japan),
RCM, CCC, KC
Planned: BIS
Performance¹ XG 85(w) Rev. 3
Firewall throughput 3 Gbps
Firewall IMIX 800 Mbps
VPN throughput 225 Mbps
IPS throughput 580 Mbps
NGFW (IPS + App Ctrl) max. 310 Mbps
Antivirus throughput (proxy) 360 Mbps
Concurrent connections 3,200,000
New connections/sec 15,000
Maximum licensed users unrestricted
Physical interfaces
Storage 8 GB eMMC
Ethernet interfaces (fixed) 4 GbE copper
I/O ports (rear) 2 x USB 2.0
1 x Micro-USB
1 x COM (RJ45)
Power supply External auto ranging DC: 12V, 100-240VAC, 24W@50-60 Hz
Physical specifications
Mounting Rackmount kit available
Dimensions
Width x Depth x Height 190 x 117 x 43 mm
7.48 x 4.61 x 1.69 inches
Weight 0.75 kg / 1.65 lbs (unpacked)
1.9 kg / 4.19 lbs (packed)
Gebraucht, factory reset.
)
)
